The Kübler Sendix K58I family combines high-resolution measurement, robust construction and flexible configuration for demanding industrial applications. Available in standard and Performance versions, the Ø58 mm encoder platform offers different levels of resolution and temperature capability to meet a wide range of automation requirements.
Both versions use optical scanning technology and are available with Push-Pull or TTL/RS422 interfaces, with shaft and hollow-shaft configurations.
K58I vs. K58I Performance
| Feature | Sendix K58I | Sendix K58I Performance |
|---|---|---|
| Housing diameter | Ø58 mm | Ø58 mm |
| Resolution | Up to 5,000 ppr | Up to 36,000 ppr |
| Operating temperature | -40°C to +85°C | -40°C to +110°C |
| Protection | Up to IP67 | Up to IP67 |
| Max. speed | 12,000 rpm | 12,000 rpm |
| Scanning | Optical | Optical |
| Interfaces | Push-Pull, TTL/RS422 | Push-Pull, TTL/RS422 |
| Through hollow shaft | Up to 25 mm | Up to 25 mm |
| Programmable parameters | – | Yes |
The Sendix K58I provides reliable incremental measurement with resolutions up to 5,000 ppr, making it suitable for a wide range of industrial automation and motion control applications.
The K58I Performance extends the same compact platform with resolutions up to 36,000 ppr and individually configurable parameters, including pulse number, counting direction and zero pulse settings. Its extended temperature range makes it particularly suitable for applications exposed to higher operating temperatures.
Both versions feature Kuebler’s Safety-Lock technology and an optimized EMC shielding concept, supporting reliable operation in demanding industrial environments. The encoders are also prepared for applications involving digital nameplates and digital twins for machine monitoring and maintenance.
The Sendix K58I family is therefore a flexible solution for applications requiring reliable speed and position measurement, with the Performance version offering additional resolution and configuration flexibility.
IAS – L. I. Skourgialos L.P. provides Kuebler encoder solutions in Greece and Cyprus. Contact us to select the appropriate Sendix K58I configuration for your application.
